  Hebot II & Hebot Robot | Previous | 1 | 2 | Next |


Hebot II Robot
Click to Enlarge

Hebot II Robot
Click to Enlarge

Hebot II Robot
Click to Enlarge

Hebot II Robot
Click to Enlarge

Hebot II Robot
Click to Enlarge


HEBOT I, II & III Robot
Click to Enlarge

HEBOT I, II & III Robot
Click to Enlarge

HEBOT I, II & III Robot
Click to Enlarge

HEBOT I, II & III Robot
Click to Enlarge


HEBOT I, II & III Robot
Click to Enlarge

HEBOT I, II & III Robot
Click to Enlarge

HEBOT I, II & III Robot
Click to Enlarge

HEBOT I, II & III Robot
Click to Enlarge

Hebot II Robot is a free roaming robot which can negotiate obstacles, steer towards a light and follow a wire around your home. The robot emits a squeak when it detects light or following a collision. Control is transferred to the wire following circuitry unless HEBOT encounters an abstacle. HEBOT also has a microphone, and can be wired to go into reverse, spin, or just stop. HEBOTs random walking is a bit of a misnomer, as it actually executes a series of spirals.

HEBOT I, II & III – John FitzGerald 1979-80 (British) - - Hobby Electronics magazine (November 1979-January 1980) describes an autonomous robot. HEBOT is a free roaming robot which can negotiate obstacles, steer towards a light (infra red) and follow a wire (A.C. current) around your home. HEBOT emits a squeak when it detects light or following a collision. Control is transferred to the wire following circuitry unless HEBOT encounters an abstacle. HEBOT also has a microphone, and can be wired to go into reverse, spin, or just stop. HEBOT's 'random walking' is a bit of a misnomer, as it actually executes a series of spirals.

Cyberneticzoo.com : - - 1979-80 HEBOT I, II & III – John FitzGerald (British)
Davidbuckley.Net : - - Hebot-II was a look-alike for the MIT-turtle.



Source: Cyberneticzoo.com, Davidbuckley.Net, Internet & Research - Updated 04-14-2021
